It is applicable to products and samples with strict storage requirements, and ideal for long-term storage, meeting the typical storage needs of hospitals, disease control centers, research institutions, and biomedical engineering institutes.

Product Features.

Featuring a space-saving design, it offers full-performance ULT storage for benchtop setups, stacked arrangements, or undercounter installations.

Ideal for precisely regulated temperature changes across an expansive set point range of – 86°C to – 20°C, maintaining a temperature uniformity of ≤±2°C.

Optimized for energy efficiency delivering a power consumption of just 3 kWh/day at -80°C.

The advanced refrigeration system utilizes 100% natural refrigerants to reduce the impact on climate.

Adopting the PID temperature control technology enables precise temperature control and keeps the temperature fluctuation within ±0.5°C from -20°C to -86°C.



Model Temperature Range (°C) Power Supply (V/Hz) Capacity (L/Cu.Ft) Exterior Dimension (W*D*H)(mm) Certifications
DW-86L100STL -20~-86 220~240/50/60 | 110~120/50/60 100/3.5 779*820*816 CE | UL

Documentation

SKUProductTypeLanguageFile
DW-86L100STLDW-86L100STLFlyerEnglishDownload
