Key Features:

  • Same as n-GUARD, but with materials resistant to harsh chemicals;
  • Enhanced safety against corrosive substances;
  • Ideal for inorganic chemistry, environmental laboratories, where strong acids are used;
  • High durability in aggressive environments.

Available in sizes 1200, 1500 and 1800.

Technical specifications

Specification nGUARD 1200 PRO nGUARD 1500 PRO nGUARD 1800 PRO
External width (mm) 1200 1500 1800
Internal width (mm) 1050 1350 1650
External depth (mm) 845
External depth incl. media (mm) 865
Internal depth (mm) 662
External height for ducting 2195, at 900 mm working height
External height incl support stand (mm) 2080 with recessed legs on stand
External height w/o support stand (mm) 1490
Max height with open sash 2062
Work height (mm) 700 -1050  (Adjustable fixed) / 750 -1050  (Electrical stand)
Free leg space underneath (mm) 830 , at 900  work height
Light Min. 1000 Lux
Sash window (mm) 6  laminerat glas
Sash window design Double PVC-cover stainless steel wire
Material work top Stainless steel (316)
Side panel Standard
Media standard + Max no 5 pcs as standard
Electrical outlet standard + Max antal 2 pcs as standard
RCD, Residual circuit breaker Standard
Ø Duct connection (mm) 250 315 315

Dimensions

Specification nGUARD 1200 PRO nGUARD 1500 PRO nGUARD 1800 PRO
External width  (mm) 1200 1500 1800
Internal width (mm) 1050 1350 1650
Closed sash (6 cm open) l/s 40 50 60
40 cm sash opening l/s 210 270 330

Documentation

SKUProductTypeLanguageFile
BrochureEnglishDownload
Dimensions

1200, 1500, 1800
