Used for storage of medicines, vaccines, reagents, biological products and other items that require a temperature between 2-8°C in hospitals, pharmacies, pharmaceutical factories, clinics and laboratories as key examples.

Product Features

  • Ergonomic & innovative design, 7” touch screen, easy to check the cabinet temperature, alarm & event records; authority management is standard to avoid unauthorized access or change in settings
  • Triple-paned tempered glass door with frame heater to reduce condensation even at 32 ° C, 80% RH ambient; self-closing door with 90 ° stop; magnetic gaskets to ensure a positive seal;
  • Multiple alarm functions for safer monitoring, audible/visual alert with mute function; remote alarm contact is equipped as standard;
  • Anti-freezing thermostat is available to protect store items from freezing, which is DIN13277 compliance;
  • Energy efficient interior LED lighting, side-mounted for complete clear visibility of the internal area;
  • Standard USB module to easily record and export cabinet temperature and alarm data; Standard RS485 port and remote alarm contact for ease of external connection; optional printer to efficiently export cabinet temp data;
  • Microprocessor controller, smart inverter compressor, optimized air-cooling technology with auto defrost to ensure excellent cooling performance, defrost water to evaporate automatically;
  • Two 25mm probe access ports on each side wall to accept user-provided monitoring equipment;
  • Adjustable plastic-coated wire shelves for improved circulation and flexible storage, 4 swivel casters with 2 leveling feet for easy movement and fixing;
  • Electromagnetic lock is standard to avoid unauthorized access.



Model Power Supply (V/Hz) Power Consumption (kWh/day) Capacity (L/Cu.Ft) Exterior Dimensions (W*D*H)(mm) Shelves/Drawers Certification
HYC-1030GT 220~240/50/60 2.2 1030/36.4 1205*830*1990 14/0 CE, DIN13277 (Optional)

Documentation

SKUProductTypeLanguageFile
HYC-1030GTHYC-1030GTFlyerEnglishDownload
CatalogueEnglishDownload
